The Steel Shapes module is a structural add-on for AutoCAD that easily draws w-shapes, channels, single/double angles, square & rectangular tubing, pipes, M, S, HP shapes and tees as listed in the AISC database. It also includes metric databases included MAISC and CISC if needed. Steel Shapes Features • Create shapes in plan, section, elevation or single line as required. • Create simple or complex shapes made from a single non-segmented polyline. • Shapes are created as an AutoCAD block to keep file size minimized. • Ability to cope ends of W-Shapes in elevation view. • List shape properties from drawing after shape placement or within dialog box.

• All shapes are created parametrically from external data files. • Shapes are attached to cursor based on insertion point selected and rotated after placement. • Automatic shape notation by selecting inserted shape. • User defined dimensions for shape details. Steel Shapes operates using one main dialog that allows access to all shapes allowing multiple insertion points, layer, color and linetype control. In addition specify dimensions for details, before placing the shape in your AutoCAD dtrawing.

Product Description Autocad steel shapes Sweep Shape is another free Awesome AutoCAD Plug-in developed for detailing, 3D structural Steel Profiles based on user selected polylines/lines or by choosing the start and end point. It’s actually an upgrade to There are many profiles available from L Shape to IPE And many more. Send us your request and we will add more Autocad steel shapes to come on next release. The programs were written in AutoLisp By Stefan M. For educational purpose only. After purchasing (Free) the app you will receive an email containing a link to download the program and a unique license code, this code will be used to activate the program.

After installation and activation you can call the command by typing “ SWS” (SweepShape, left hand friendly) Check out the video below for a short demo showing the program features. Note: This program tested with AutoCAD 2012, 2013,2014,2015,2016. Nasa Blue Marble Geotiff Download. (And verticals).
